Online TOC sensor
Key specifications:
✅Range 0-500mg/L(Customisable)
✅RS485,MODBUS protocol
✅Ultraviolet absorption method
✅Easy on-site use
✅Self-cleaning system
TOC sensor is a device for real-time monitoring of total organic carbon (TOC) content in water bodies through UV absorption technology, which is widely used in water quality monitoring, industrial water treatment and other fields.
Product Features
✅digital sensor, RS-485 output, MODBUS support;
✅No reagents required, no pollution, more economical and environmentally friendly.
✅Can measure parameters such as TOC, COD,turbidity and temperature.
✅Automatically compensates for turbidity interference
✅With automatic cleaning brush to prevent biological attachment and longer maintenance cycle.
Technical parameter
| Name | Online TOC Sensor |
| Principle | Ultraviolet absorption method |
| Range | 0-500mg/L(Support for customisation,Max 0-3000mg/L) |
| Accuracy | ±5%FS |
| Resolution | 0.01mg/L |
| Linearity | R2 > 0.99 |
| Protection Level | IP68 |
| Output Signal | Support RS-485/Modbus protocol |
| Operating Temp. | 0-50℃ |
| Sensor Installation | Immersion mode |
| Power Supply | DC 12V, current < 50mA |
| Cable Length | 5 meters (default),Customizable |
| Housing Material | 316L/Titanium |
