Handheld turbidity meter is a portable device to measure the turbidity of water. The matching turbidity sensor adopts the 90° scattering principle, small size, easy to install and maintain, not easy to be disturbed by ambient light, with good repeatability and stability. There is no need to replace the diaphragm, no electrolyte, no need for frequent maintenance and calibration. The instrument is equipped with an operating keyboard and a backlight display, with a simple interface, comprehensive functions and easy operation. The instrument can easily achieve data measurement, data storage, parameter setting, sensor calibration and other functions, and supports data export. Compact and lightweight, easy to carry and on-site operation.

Product Features

✅Compact and lightweight, easy to carry and operate in the field.

✅No electrolyte required, strong anti-interference, no need for frequent calibration.

✅Stores measurement data for easy analysis and reporting.

✅Fast response time, high precision, strong stability.

✅Built-in calibration parameters, precisely calibrated before leaving the factory, can be directly installed and used.

✅Rugged design suitable for harsh environments and long-term use.

Technical parameter

Name	Handheld Turbidity Meter
Model	YCH339
Principle	90° light scattering method
Range	0.1-1000NTU or 0.1-4000NTU
Accuracy	51%FS or 0.3NTU(take the bigger one)
Data Storage	Support
Dimension	φ22*175.5mm
Working pressure	6 bar
Response time	10s
Operating Temp.	0-50℃
Timed shutdown	Support
Power Supply	Two 18650 rechargeable batteries
Cable Length	5 meters (default),Customisable
Housing Material	Titanium alloy

Product Advantages
