The optical method portable dissolved oxygen meter uses the leading international fluorescence technology. The significant advantages of this fluorescence method of DO measurement are that it does not consume oxygen, does not require polarisation, does not require frequent calibration, and is not subject to interference from H2S, heavy metals, oils and greases, acids and bases. The portable DO meter has manual input compensation for temperature, pressure and salinity. The instrument is equipped with an operating keyboard and a backlight display with a simple interface, comprehensive functions and easy operation. The instrument can easily achieve data measurement, data storage, parameter setting, sensor calibration and other functions.

Product Features

✅High-efficiency fluorescent membrane, long service life.

✅No electrolyte required, strong anti-interference, no need for frequent calibration, no oxygen consumption, no flow requirements.

✅Real-time temperature and air pressure compensation.

✅Fast response time, high precision, strong stability.

✅Built-in calibration parameters, precisely calibrated before leaving the factory, can be directly installed and used.

Technical parameters

Name	Portable DO Meter
Model	YCH261
Principle	Fluorescence method
Range	0-15mg/L or 120% saturation
Accuracy	±3%FS
Data Storage	Support
LCD size	41*50mm
Sensor size	φ20*100
Meter size	65*28*165mm
Working pressure	1 bar
Response time	20s
Operating Temp.	0-50℃
Timed shutdown	Support
Power Supply	AAA*4pcs
Cable Length	3.5 meters (default),Customizable
Housing Material	Aluminium alloy
