Product description

Summarize

The turbidity of water is calculated by measuring the scattering and absorption of light caused by suspended particles and dissolved substances in water. The automatic cleaning brush with the sensor can effectively eliminate air bubbles and reduce the impact of particles on measurement accuracy.

Peculiarity

 digital sensor, RS-485 output, MODBUS support;

 Optional self-cleaning brush to reduce the impact of bubbles;

 anti-interference ability is strong, not affected by light and chroma;

 scattered light principle, strong stability;

Technical parameter

Name Parameter Name parameter

Range 0 ~ 4000mg/l Response time < 30sec

Precision 5% F.S cable 5 meters can be customized

Resolution 1mg/l Operating temperature 0~ 50°C

Linearity R² >0.999 Power information DC12V±5% <50mA

Output signal RS-485 MODBUS Protection level IP68

Measuring method 90° scattered light Product material POM

Calibration method One point calibration water depth < 10m

Mounting thread G3/4 dimensions Φ32 X 195mm
